These premium quality E3D replacement nozzles allow you to truly customize each and every print. These nozzles have been created using community feedback and notes so they are fully optimized. This v6 nozzle has been fully redesigned. These nozzles have reduced back-pressure which allows exceptionally smooth and easy flow of filament while improving retractions.

The smaller nozzles have a small nozzle tip which offers increadible precision. The larger nozzles afford you the ability to print with larger layers.

You can easily identify all the nozzles in the series by looking at the markings on the flats of the hex head. See below to help you identify what each set of markings means in relevance to size.

Marks on Nozzle = Size

• 0 = 0.25mm
• 1 = 0.30mm
• 2 = 0.35mm

• 6 = 0.50mm
• 4 = 0.60mm
• 5 = 0.80mm

Compatibility:

• v6 Nozzles feature backwards compatibility, so they can be used to upgrade your v5 HotEnd.
• If you are using a v6 HeatBreak it is recommended that you use a v6 Nozzle.
• This nozzle is compatible with the E3D Lite6 HotEnd.
