What the OpenBuilds 2020 V-Slot Slider Motor Mounting Plate does

The OpenBuilds 2020 V-Slot Slider Motor Mounting Plate for X-Axis is an aluminum motor plate designed to mount a stepper motor securely on a V-Slot linear rail system. It provides a strong, stable mounting surface that supports smooth and precise X-axis motion in desktop and light-duty motion builds.

This black mounting plate is suited to machine designs where accurate motor positioning matters, including CNC machines, laser engravers, 3D printers, and other linear motion applications.

Key features of the X-axis motor mounting plate

• Precision-machined construction: Supports accurate and stable motor mounting for smoother motion and more consistent alignment.
• Multiple motor mounting options: Pre-drilled holes support both NEMA 17 and NEMA 23 stepper motors.
• Anodized aluminum body: Delivers a balance of strength and low weight for motion systems that benefit from durable, lightweight components.
• Designed for V-Slot systems: Built for use with OpenBuilds 2020 V-Slot linear rail configurations and similar X-axis assemblies.

Where this OpenBuilds motor plate is commonly used

This motor mounting plate is commonly used in X-axis motion systems for CNC routers, laser engravers, and 3D printers. The stable mounting surface helps keep the drive motor properly supported in builds where smooth travel and precise positioning are important.

For makers and machine builders working on custom linear motion projects, the OpenBuilds plate is also suitable for other V-Slot-based applications that require a reliable stepper motor mount along the X-axis.

Technical specifications
